GOCCOPRO QS200

The GOCCOPRO QS200 is a fast, high-end digital screen printer with accurate registration for multi-color printing. With a compact size, this screen maker is perfect for quick turn projects that need to be high quality (images print at 600 dpi resolution). This is the perfect printer for short runs and commercial printing.

Call or email for Quote

The Goccopro QS200 can burn screens as small as 6″x6″ to screens as big as  22″x31″

Description

  • Eco-Friendly: Unlike traditional screen printing, GOCCOPRO uses a thermal process that eliminates the need for emulsions, darkroom, or washout booth.
  • High Resolution and Detail: The QS200 can burn images at 600 dpi, enabling the reproduction of fine gradations, halftone dots, and other details typically found in photographs.
  • Ease of Use: The QS200 is easy to operate, requiring minimal training and no special skills. You can simply connect it to your computer and send the image data.
  • Compact: can fit on a table
  • Precise Registration: The pre-stretched screen master on the frame ensures accurate alignment when printing multiple screens, making it suitable for multi-color printing.
  • Versatile: Choose from various screen sizes from 6″X6″ frame to a 22″x31″ frame
  • Diverse: It can be used for a variety of applications, including printing on fabric, plastic, glass, metal, cardboard and other materials.

Specifications

  • Screen making method High-speed digital screen making
  • Maximum Frame Size 580mm X 780mm (22.8″ X 30.7″)
  • Maximum Image Area 420mm X 620mm (16.5″ X 24.4″)
  • Screen Making Time Within 2 minutes (A4 size)
  • Resolution 600 dpi X 600 dpi
  • Main Unit Storage 128MB
  • Supported OS Microsoft Windows® 8(32-bit/64-bit), Windows® 7(32-bit/64-bit), Windows Vista®(32-bit/64-bit), Windows® XP(32-bit), Mac OS X10.4/10.5/10.6/10.7/10.8
  • Interface USB2.0
  • Power Source AC100-240V/2.5A, 50-60Hz
  • Power Consumption Approximately 300W
  • Operating Environment Temperature:15°C-30°C / 59F-86F
  • Dimensions 980mm(W) X 720mm(D) X 480mm(H) (38.6″(W) X 28.4″(D) X 18.9″(H))
  • Weight Approximately 67kg / 148lb

Consumables

Digital Screen Maker Frame Types and Sizes:
Aluminum Frame: (19” x 23.75”) with and without frame adhesive
Quick Self Tension Screw Frames: (21”x 23”), (22” x 31”), (25” x 36”)
Newman Roller Frame: 22” x 28”

Mesh Types and Sizes:
70 Mesh: (44.5” x 10’)
1/2 Roll 70 Mesh: (22” x 10’)
120 Mesh: (44.5” x 54.7 yards)
1/2 Roll 120 Mesh: (22” x 18’)
200 Mesh: (44.5” x 18’)
1/2 Roll 200 Mesh: (22” x 18’)
